| General Data | |
|---|---|
| Item No | SS316: WLR278O / Alu: WLR280O |
| Power | 1.5 watts +-10% |
| LED Type | 1 PC 1W CREE XPE LED |
| Luminous flux | 76~95 lm |
| CCT | 2700K, 3000K, 4000K, 6000K |
| CRI | 80+ |
| Beam angle | 30°x60° (Tilt x Pan) |
| Dimension (mm) | 28.5 x 28 (mm) Diameter x Height |
| Cut out (mm) | 27 |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC12V / DC24V |
| Insulation class | Class III |
| Cable | 1PC teflon cable 0.25M 2*0.3mm square |
| Driver | low voltage constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP67 Waterproof |
| IK rating | IK06 |
| Housing | Stainless steel 316 for A version / Aluminium for B version |
| Protection Finishing | Stainless steel 316 for A version / Silver color Anodizing Aluminium for B version |
| Trim | Stainless steel 316 for A version / Silver color Anodizing Aluminium for B version |
| Glass | / |
| Loading capacity | 110 kgs |
| Cable Gland | / |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Spring | PC spring for recessed installation |
| Clip | SS304 clip for taking off the xture from the handrail |
