| General Data | |
|---|---|
| Item No | IGD0485O (RGBW)-A |
| Power | 12 Watts |
| LED Type | 3 PCS 4 watts 4in1 RGBW LED |
| Luminous flux | 900 lm (ALL LEDs ON) |
| CCT | RGB+6000K CW or 3000K WW |
| CRI | 70+ |
| Beam angle | 23°,28°,43°,58° (Direction adjustable with 20° at max) |
| Dimension (mm) | 116x72 (mm) Diameter x Height |
| Cut out (mm) | 100 mm |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC24V |
| Insulation class | Class III |
| Cable | 1PC rubber cable 1.5M H05RN-F 5x0.75mm squLow voltag are e |
| Driver | constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP67 Waterproof |
| IK rating | IK09 |
| Housing | Solid Passivated (Anodizing) Aluminum CNC machined |
| Protection Finishing | 20~25μm thickness anodized film for housing. Dark grey |
| Trim | Stainless steel 316 |
| Glass | Step tempered Glass. T=8mm. |
| Loading capacity | 2000 kgs |
| Cable Gland | PG9 IP67 |
| Gasket | O-ring PMQ silicone seal |
| Rotatable | Manual rotationg bracket max 20°+20° |
| Accessories | |
|---|---|
| Mounting sleeve | Solid Passivated (Anodizing) Aluminum CNC machined |
