| General Data | |
|---|---|
| Item No | IGD0176O |
| Power | 3 Watts |
| LED Type | 6PCS 5050 3in1 RGB SMD LED |
| Luminous flux | 90 lm (All LEDs on) |
| CCT | RGB |
| CRI | 70+ |
| Beam angle | 120° |
| Dimension (mm) | 60x49 (mm) Diameter x Height |
| Cut out (mm) | 58 mm |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC12V /DC24V |
| Insulation class | Class III |
| Cable | 1PC rubber cable 0.3M H05RN-F 4x0.5mm square |
| Driver | Low voltage constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP67 Waterproof |
| IK rating | IK06 |
| Housing | Solid Passivated (Anodizing) Aluminum CNC machined |
| Protection Finishing | 20~25μm thickness anodized film for housing. Dark grey |
| Trim | Solid Passivated (Anodizing) Aluminum CNC machined |
| Glass | Step tempered Glass. T=5.5mm. |
| Loading capacity | 320 kgs |
| Cable Gland | PG7 IP67 |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Mounting Sleeve | Anti-corrosion PVC. Grey |
| Round base | With SS304base for concrete ground installation |
