| General Data | |
|---|---|
| Item No | WLS176O |
| Power | 18 Watts |
| LED Type | 1PC 3030 RGB LED |
| Luminous flux | 1800 lm |
| CCT | 2700 ~ 6500K |
| CRI | 80+ |
| Beam angle | 15°,25°,38,°,45° |
| Dimension (mm) | 220x220x67.5 |
| Cut out (mm) | 200 mm |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC24V |
| Insulation class | Class III |
| Cable | 1PC rubber cable 1M H05RN-F 5x0.5mm square |
| Driver | Low voltage input, constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP68 Waterproof |
| IK rating | IK06 |
| Housing | Stainless steeel 316 |
| Protection Finishing | Stainless steeel 316 |
| Trim | Stainless steeel 316 |
| Glass | Step tempered Glass. T=4mm. |
| Loading capacity | 320 kgs |
| Cable Gland | PG gland |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Mounting Sleeve | Anti-corrosion grey PVC tube (Convex type box as optoins) |
