| General Data | |
|---|---|
| Item No | WLR206O |
| Power | 3 / 9 / 12 / 15 / 27/ 30 W |
| LED Type | CREE COB LED |
| Luminous flux | 120 lm/w |
| CCT | 2700,3000,4000,6000K |
| CRI | 80+ |
| Beam angle | 30° |
| Dimension (mm) | 114x114x65 / 170x114x65 / 226x114x65 |
| Cut out (mm) | 100x100 / 150x150 / 200x200 |
| Life Time: | 50,000Hrs |
| Adjustable | No |
| Working Temp | -20° ~ +50° |
| Surge protection | / |
| Construction Data | |
|---|---|
| IP rating | IP65 |
| Finishing | Grey |
| Housing | Aluminum |
| Diffuser | PC |
| Accessories | |
|---|---|
| / | |
| OPTIONS | |
|---|---|
| Emergency | Yes |
| Dimmable | Yes |
| Electrical Data | |
|---|---|
| Input voltage | AC 110~240V |
| Insulation Class | I |
| Cable | Open wires |
| Driver | Integrated High voltage driver |
