| General Data | |
|---|---|
| Item No | WLR204O |
| Power | 3 / 9 / 12 / 15 / 27/ 30 W |
| LED Type | CREE / Luminus COB LED |
| Luminous flux | 120 lm/w |
| CCT | 2700,3000,4000,6000K |
| CRI | 80+ |
| Beam angle | no lens |
| Dimension (mm) | 48x48x26 |
| Cut out (mm) | Ø45x95 for installation box |
| Life Time: | 50,000Hrs |
| Adjustable | No |
| Working Temp | -20° ~ +50° |
| Surge protection | / |
| Construction Data | |
|---|---|
| IP rating | IP40 |
| Finishing | White Black Grey |
| Housing | Aluminum |
| Diffuser | Clear PC |
| Accessories | |
|---|---|
| / | |
| OPTIONS | |
|---|---|
| Emergency | Yes |
| Dimmable | Yes |
| Electrical Data | |
|---|---|
| Input voltage | 350mA |
| Insulation Class | I |
| Cable | Open wires |
| Driver | External low voltage driver |
