| General Data | |
|---|---|
| Item No | UWL222U |
| Power | 1.5 watts (3 watts optional for underwater) |
| LED Type | 1 PC CREE XPE LED |
| Luminous flux | 90~95 lm |
| CCT | 2700K, 3000K, 4000K, 6000K, R/G/B/A |
| CRI | 80+ |
| Beam angle | 25°, 15°, 38°, 45°, 60°, 120° optional. |
| Dimension (mm) | 45 x 36 (mm) Diameter x Height |
| Cut out (mm) | 40mm |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC12V/DC24V |
| Insulation class | Class III |
| Cable | 1PC rubber cable 1M H05RN-F 2x1mm square |
| Driver | Low voltage constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP68 Waterproof |
| IK rating | IK06 |
| Housing | Stainless steel 316 as standard, (solid Passivated (Anodizing) Aluminum CNC machined as options) |
| Protection Finishing | 20~25μm thickness anodized film for Aluminum housing. |
| Trim | Stainless steel 316 |
| Glass | Tempered Glass. T=4mm |
| Loading capacity | 320 kgs |
| Cable Gland | PG7 IP68, Glue |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Mounting Sleeve | Anti-corrosion grey PVC |
