| General Data | |
|---|---|
| Item No | SLRC502I / SLRC504I / SLRC506I / SLRC508I |
| Power | 15 / 20 / 25 W |
| LED Type | CREE COB LED |
| Luminous flux | 120 lm/w |
| CCT | 2700 , 3000 , 4000 , 6000 K |
| CRI | 80+ |
| Beam angle | 17° / 25° / 36° / 60° |
| Dimension (mm) | Ø135x188 |
| Cut out (mm) | 42*42 /42*115 /80*80 /42*195 /117*117 /42*383 |
| Life Time: | 50,000 Hrs |
| Adjustable | No |
| Working Temp | -20°~ +50° |
| Surge protection | Yes |
| Construction Data | |
|---|---|
| IP rating | IP20 |
| Finishing | White, Black |
| Housing | Aluminum |
| Diffuser | Lens |
| Reflector | Black/Chrome/Gold |
| Accessories | |
|---|---|
| / | |
| OPTIONS | |
|---|---|
| Emergency | Yes |
| Dimmable | Yes |
| Electrical Data | |
|---|---|
| Input voltage | AC100~240V |
| Insulation Class | I |
| Cable | Open wires |
| Driver | Integrated high voltage driver |
