| General Data | |
|---|---|
| Item No | PRL148O |
| Power | 3 Watts |
| LED Type | 1 PC 5W CREE COB LED |
| Luminous flux | 350~400 lm |
| CCT | 2700K, 3000K, 4000K, 6000K |
| CRI | 80+ |
| Beam angle | 15°, 24° |
| Dimension (mm) | 44 x 90 (mm) Diameter x Height |
| Cut out (mm) | / |
| Life Time: | 50,000 Hrs |
| Working Temp | 20 ~ +50 |
| Certifications | CE, RoHS0 |
| Electrical Data | |
|---|---|
| Input voltage | AC100-265V as standard (DC 12V or DC 24V as optional) |
| Insulation class | Class I |
| Cable | 1PC rubber cable 1M or 2M H05RN-F 3x1mm square |
| Driver | Built-in high voltage constant current driver with transformer |
| Construction Data | |
|---|---|
| IP rating | IP65 Waterproof |
| IK rating | IK04 |
| Housing | Solid Passivated (Anodizing) Aluminum CNC machined |
| Protection Finishing | 20~25μm thickness anodized film for housing. Dark grey as standard, silver color,black color, or powder coated painted in white color as options. |
| Trim | Passivated (Anodizing) Aluminum |
| Glass | Step tempered Glass. T=3mm. |
| Loading capacity | 220 kgs |
| Cable Gland | PG7 IP67 |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Spike | With 1200mm stainless steel 304 stick +205mm Aluminium spike optional |
| Round base | Round base for surface mounting as options |
