| General Data | |
|---|---|
| Item No | IGD0455O |
| Power | 7.5 Watts |
| LED Type | 30 PCS OSRAM 2835 SMD LED |
| Luminous flux | 330~350 lm |
| CCT | 2700K, 3000K, 4000K, 6000K, R/G/Y/B |
| CRI | 80+ |
| Beam angle | Assymetrical 30° tilt +120° pan beam |
| Dimension (mm) | 210 x 63 x 78 (mm) Length x Width x Height |
| Cut out (mm) | 185 x 57 x 75 (mm) Length x Width x Height |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | AC100-255V |
| Insulation class | Class I |
| Cable | 1 PC rubber cable 1M H05RN-F 3x1mm square |
| Driver | Built-in high voltage constant current driver with transformer |
| Construction Data | |
|---|---|
| IP rating | IP67 Waterproof |
| IK rating | IK08 |
| Housing | Passivated (Anodizing) Aluminum |
| Protection Finishing | 20~25μm thickness anodized film for housing. Dark grey |
| Trim | Stainless steel 316 |
| Glass | Step tempered Glass. T=8mm. |
| Loading capacity | 2000 kgs |
| Cable Gland | PG9 IP67 |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Mounting sleeve | Passivated (Anodizing) Aluminum CNC machined. Dark grey |
| Packaging | |
|---|---|
| Inner box size | 220*85*95mm |
| Carton size | 44.5*23.5*21 cm (10PCS / carton) |
