| General Data | |
|---|---|
| Item No | IGD0368O |
| Power | 3 Watts |
| LED Type | 1 PC 3W 3in1 LED |
| Luminous flux | 105 lm (All LEDs on) |
| CCT | 105 lm (All LEDs on) |
| CRI | 70+ |
| Beam angle | 25°, 45° |
| Dimension (mm) | 55 x 70 (mm) Diameter x Height |
| Cut out (mm) | 80 mm |
| Life Time: | 50,000 Hrs |
| Working Temp | 20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC12V |
| Insulation Class | Class III |
| Cable | 1PC rubber cable 1.5M H05RN-F 4x0.75mm square |
| Driver | Low voltage constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP67 Waterproof |
| IK rating | IK09 |
| Housing | Solid Passivated (Anodizing) Aluminum CNC machined |
| Protection Finishing | 20~25μm thickness anodized flm for housing. Dark grey |
| Trim | Stainless steel 316 |
| Glass | Step tempered Glass. T=8mm. |
| Loading capacity | 320 kgs |
| Cable Gland | PG9 IP67 |
| Gasket | O-ring PMQ silicone seal |
