| General Data | |
|---|---|
| Item No | IGD0332O |
| Power | 1 Watts |
| LED Type | 1 PC 1W OSRAM LED |
| Luminous flux | 95~100 lm |
| CCT | 2700K, 3000K, 4000K, 6000K, R/G/Y/B |
| CRI | 80+ |
| Beam angle | 120° |
| Dimension (mm) | 40 x 12 (mm) Diameter x Height |
| Cut out (mm) | 38 mm |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC12V/DC24V |
| Insulation class | Class III |
| Cable | 1PC PVC cable 0.3M 2x0.34 mm square |
| Driver | Low voltage constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP65 Waterproof |
| IK rating | IK06 |
| Housing | Solid Passivated (Anodizing) Aluminum CNC machined |
| Protection Finishing | 20~25μm thickness anodized film for housing,Dark grey |
| Trim | Stainless steel 316 as standard, Polished chrome Aluminium as options |
| Glass | Step tempered Glass. T=4mm. Frosted glass as standard, milky white glass as options. |
| Loading capacity | 320 kgs |
| Cable Gland | Glue |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Mounting sleeve | Aluminium spring fixed on the body |
