| General Data | |
|---|---|
| Item No | IGD0281O (LOGO) |
| Power | 6 Watts |
| LED Type | 3 PCS OSRAM LED |
| Luminous flux | 10~12 lm |
| CCT | 2700K, 3000K, 4000K, 6000K |
| CRI | 80+ |
| Beam angle | 120° |
| Dimension (mm) | 150 x 40 (mm) Diameter x Height |
| Cut out (mm) | 138 mm |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC24V |
| Insulation class | Class III |
| Cable | 1PC rubber cable 1M H05RN-F 2x1mm square |
| Driver | low voltage constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP67 Waterproof |
| IK rating | IK06 |
| Housing | Solid Passivated (Anodizing) Aluminum CNC machined |
| Protection Finishing | 20~25μm thickness anodized film for housing. silver color |
| Trim | Stainless steel 316 |
| Glass | Tempered Glass. T=6mm. |
| Loading capacity | 320 kgs |
| Cable Gland | PG7 IP67 |
| Gasket | O-ring PMQ silicone seal |
| Accessories | |
|---|---|
| Mounting sleeve | Anti-corrosion grey PVC |
| Clip | 2 pcs SS304 spring with screws as options |
