| General Data | |
|---|---|
| Item No | IGD0125O (RGB) |
| Power | 9 Watts |
| LED Type | 3 PCS 3W 3in1 LED |
| Luminous flux | 540 lm (ALL LEDs ON) |
| CCT | RGB |
| CRI | 70+ |
| Beam angle | 25°, 45° (Direction adjustable with 20° at max) |
| Dimension (mm) | 116 x 72 (mm) Diameter x Height |
| Cut out (mm) | Inground light: Ø118 mm Deck light: Ø115 mm |
| Life Time: | 50,000 Hrs |
| Adjustable | / |
| Working Temp | -20°~ +50° |
| Surge protection | / |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | DC12V |
| Insulation Class | Class III |
| Cable | 1PC rubber cable 1.5M H05RN-F 4x0.75mm square |
| Driver | Low voltage constant current output, excluding the transformer |
| Construction Data | |
|---|---|
| IP rating | IP67 Waterproo |
| IK rating | IK09 |
| Housing | Solid Passivated (Anodizing) Aluminum CNC machined |
| Protection Finishing | 20~25μm thickness anodized film for housing. Dark grey |
| Trim | Stainless steel 316 |
| Glass | Step tempered Glass. T=8mm. |
| Loading capacity | 2000 kgs |
| Cable Gland | PG7 IP67 |
| Gasket | O-ring PMQ silicone seal |
| Rotatable | Manual rotationg bracket max 20°+20° |
| Accessories | |
|---|---|
| Mounting Sleeve | Aluminium sleeve optional used as inground light and Two clips with screws used as downlight / deck light |
| OPTIONS | |
|---|---|
| Emergency | / |
| Dimmable | / |
