| General Data | |
|---|---|
| Item No | FDL090O |
| Power | 10 / 20 / 30 / 50 / 80 / 100 / 150 / 200 / 240 / 300 W |
| LED Type | Lumileds 3030 |
| Luminous flux | 130 lm/w |
| CCT | 2700 ~ 6500K |
| CRI | 80+ |
| Beam angle | 30° / 60° / 90° / 120° / 30x90° |
| Dimension (mm) | 182x122x47 / 242x169x51 / 284x220x52 368x269x52 / 368x269x52 / 352x394x57 446x393x57 / 427x393x59 / 427x393x59 504x546x65 |
| Cut out (mm) | / |
| Life Time: | 50,000 Hrs |
| Adjustable | YES |
| Working Temp | -20° ~ +55° |
| Surge protection | Yes |
| Electrical Data | |
|---|---|
| Input voltage | AC100~245V |
| Insulation Class | I |
| Cable | Open wires |
| Driver | Integrated high voltage driver |
| Construction Data | |
|---|---|
| IP rating | IP66 |
| Finishing | Grey |
| Housing | Die casting Aluminum housing |
| Diffuser | PMMA lens + tempered glass |
| Accessories | |
|---|---|
| Bracket / Photocell / Shorting cap | |
| OPTIONS | |
|---|---|
| Emergency | YES |
| Dimmable | YES |
