| General Data | |
|---|---|
| Item No | BTL209I |
| Power | 30 W |
| LED Type | SMD LED CHIP |
| Luminous flux | 3900 lm |
| CCT | 2700 ~ 6000K |
| CRI | 80+ |
| Beam angle | 160° |
| Dimension (mm) | 1200x66x59 |
| Cut out (mm) | / |
| Life Time: | 50,000 Hrs |
| Adjustable | No |
| Working Temp | -20°~ +50° |
| Surge protection | Yes |
| Construction Data | |
|---|---|
| IP rating | IP20 |
| Finishing | White |
| Housing | Polycarbonate (PC) |
| Diffuser | PC Cover |
| Accessories | |
|---|---|
| / | |
| OPTIONS | |
|---|---|
| Emergency | Yes |
| Dimmable | Yes |
| Electrical Data | |
|---|---|
| Input voltage | AC100~277V |
| Insulation Class | I |
| Cable | Open wires |
| Driver | Integrated high voltage driver |
