| General Data | |
|---|---|
| Item No | BLD103O |
| Power | 8 Watts |
| LED Type | With 2 PCS replaceable in two sides |
| Luminous flux | 200~240 lm |
| CCT | 2700K, 3000K,4500K,6000K |
| CRI | 80+ |
| Beam angle | 120° + 120° |
| Dimension (mm) | 140 x 90 x 300 (mm) Length x Width x Height |
| Cut out (mm) | / |
| Life Time: | 50,000 Hrs |
| Working Temp | -20 ~ +50 |
| Certifications | CE, RoHS |
| Electrical Data | |
|---|---|
| Input voltage | AC100~240V |
| Insulation class | Class I |
| Cable | 2 x cable 0.3 M H05RN-F 3x0.75mm square to open wires |
| Driver | Built-in high voltage constant current driver with transformer |
| Construction Data | |
|---|---|
| IP rating | IP65 Waterproof |
| IK rating | IK06 |
| Housing | Aluminium coated painted in white color |
| Protection Finishing | Aluminium coated painted in white color |
| Trim | Aluminium coated painted in white color |
| Glass | Tempered glass painted in milky white,T=4mm |
| Loading capacity | 320 kgs |
| Cable Gland | PG7 IP67 |
| Gasket | Flat PMQ silicone seal |
| Accessories | |
|---|---|
| Cover | Aluminium cover available for sealing one side that's without wall lights. |
